HM8-400K Woodchipper


16" Crane Fed Chipper

HM 8 - 400 K is an entry - level machine in the professional sector.  With a trailing axle and no loading crane, this drum chipper is ideally suited for feeding with an excavator or tractor mounted crane.  The large top infeed roller ensures safe reliable processing even with bulky material.  Heizohack chippers are equipped with a low drag drum chipper allowing the possibility of low drive performance and reduced fuel consumption.

Standard features:

  • Infeed dimensions: 400 x 708 mm
  • Trunk ⌀ 400 mm
  • 900 mm long chain infeed conveyor
  • 1500 mm long infeed table
  • ⌀ 520 mm pressure infeed roller
  • Std. sieve: 35/40 mm with stop bars
  • ⌀ 495 mm chopping drum with quick - change knives
  • PTO driven from tractor turning a V - Belt transmission
  • Flywheel dimensions: ⌀ 1370 mm by 90 mm wide
  • Discharge spout: foldable, pivoting and adjustable end flap all hydraulically controlled
  • Chipper controls: auto load - sensing infeed (stress control), adjustable infeed speed, infeed direction reversible, remote control with 10 m cable & control panel for all functions
  • 40 km/h chassis

Optional extras:

  • Infeed table: hydraulically folding with chain conveyor and additional intake roller
  • Opt. sieves: 35/45, 45/60 or 60/80 + stop bars
  • Crane mountable: Palfinger Epsilon C45F 67
  • Optional tyre sizes
  • Reversing camera
  • Central lubrication system
  • Foot pedal & radio control options
  • Cone splitter (on twin axle models)
  • Rear hitch options

Link to manufacturer:

Infeed Height400 mm
Infeed Width708 mm
Power Required120 + hp (150 ideally)
Output30 - 40 ㎥/hr
Number of Blades8
Infeed Roller Diameter600 mm
Chipping Drum Diameter495 mm
Infeed Table Length1500 mm
Standard Sieve50/50 mm + stop bars
Flywheel Diameter1370 mm
Flywheel Mass470 kg
Transport Dimensions3210 x 2464 x 4450 mm (HxWxL)
Working Dimensions4400 x 3904 x 4450 mm (HxWxL)
Country of ManufactureGermany
